Dimensions
Blade Size
Width
Height
Depth
12
16
16
9
16
20
20
13
20
24
24
14
24
28
28
16


Blade
Size
Model
H.P.
R.P.M.
Shp.
Wgt.
0"S.P.
CFM
1/8"SP
1/4"SP
12
D1207
1/15
1050
20
1305
750
430
16
D1607
1/15
1050
27
1560
1170
880
D1625
1/4
1725
32
2690
2460
2250
D1625-2
1/4 - 1/12
1725-1140
36
2690-1780
2460-1460
2250-1200
20
D2025
1/4
1725
35
3100
2780
2430
D2025-2
1/4 -1/12
1725-1140
39
3100-2055
2780-1860
2430-1590
D2033
1/3
1725
37
3920
3520
3170
D2033-2
1/3-1/9
1725-1140
46
3920-2590
3520-2330
3170-2100
24
D2425
1/4
1725
43
3680
3250
2460
D2425-2
1/4-1/12
1725-1140
47
3680-2440
3250-1990
2460-1630
D2433
1/3
1725
45
4390
4070
3800
D2433-2
1/3-1/9
1725-1140
54
4390-2900
4070-2690
3800-2510
D2450
1/2
1725
50
5020
4720
4450
D2450-2
1/2-1/6
1725-1140
57
5020-3320
4720-3120
4450-2940

NOTE:

All models shown with "-2" are two speed.
